TECHNICAL INFORMATION

VOLTAGE RANGEUp to 69kV
CURRENT RANGEUp to 8000A
CABLE TYPES (ALUMINUM/COPPER)USA: XHHW-2, RHH/RHW-2, MV-105
CANADA: RW90, DLO, MV-105
AVAILABLE CABLE SIZESUp to 1000MCM
CABLE CONFIGURATIONSAC: 3 phase, 3 wire | 3 phase, 4 wire
DC: 2 pole | 1 pole
ENCLOSURE SIZEUp to 12in (H) x 36in (W)
ENCLOSURE MATERIALSAluminum, Stainless Steel, Painted Options Available
CERTIFICATIONS (USA)NEMA VE-1, NFPA 70 Article 370 Compliant
CERTIFICATIONS (CANADA)CSA C22.2 No. 273:19 (Cable Bus), CSA C22.2 NO. 126.1:17 (Cable Tray), CE Code Compliant
SHORT CIRCUIT RATINGUp to 200kA
MIN/MAX AMBIENT TEMP-40°C to 60°C (-40°F to 140°F)
UNDERGROUND OPTIONSPrecast or cast-in-place, pedestrian or heavy traffic grade, with/without ventilation
CABLE SECURING METHODBlock style. Max every 30in
